Material

Aluminum die-casting+ABS

Colour

White/Black

Size

182mmx85mmx85mm

Weight

~500g

Temperature

-40°C~85°C

Power Supply Mode

IP54

Vibration/Shock

IS016750-3:2012

Power Supply

Built in 5200mAh lithium battery

Power Dissipation

Peak Power 12.6W；Average Power 5W

Hardware Specifications

LTE-V2X

Operating Frequency：5905-5925MHz；Working Bandwidth：10/20MHz；Maximum Rate：31.7Mbps
Transmission Power：23dBm；Conductive Receiving Sensitivity：-97dBm

WIFI/BT

2.4GHz/5GHz Dual Frequency WiFi，Support IEEE 802.11b/g/n/agreement；Support Bluetooth 4.2 agreement

4G

Use LTE3GPP Cat1 Technology，Support maximum downlink rate 10Mbps and maximum uplink speed 5Mbps

GNSS

Support BDS/GPS/OZSS Multi system joint positioning，Support 10Hz data update frequency；
Support centimeter level positioning，Accuracy can reach 2.5cm+lppm（CEP.50%，RTK access service is required）；
Support Inertial Navigation Function，GNSS signal loss for 60 seconds，Deviation in driving distance ≤5%；

Communication Ability

V2X communication distance greater than 500m

Information Security

Built in dedicated security chip，supporting secure national standard protocols，
with a signature/verification capability of over 2000 per second

Interface

External interfaces：1 TvpeA USB interface、1 TvpeC USB charging interface；
Antenna interface (built-in)：V2X antenna * 2、LTE antenna * 1、 WiFi/BT antenna * 1、High-precision GNSS antenna * 1；

Software Function

V2X Function

Support first stage and second stage standard V2X scenarios；Support user-defined V2X scene requirements

OTA Function

The system software supports OTA online upgrade

Voice Function

Support V2X warning scenario voice broadcast prompt function
