RSU Shell

Cast Aluminum

Colour

Silvery

Weight

~2.67kg

Dimension

300mm×268mm×80mm

Vibration/Shock

GB-T 2423.56-2006

Power Consumption

≤12W

Power Supply

POE

Operating Temperature

-40℃～ +85℃

Enclosure

IP67

Hardware Specifications

WiFi

2.4GHz/5GHz dual band WiFi, supporting IEEE 802.11 a/b/g/n/ac protocol

5G

3GPP Rel.15 technology is adopted; Support the maximum peak downlink rate of 4.67Gbps/uplink rate of 550MbpsB8

LTE-V2X

Frequency range: 5905-5925MHz; Working bandwidth: 10/20MHz; Maximum rate ：31.7Mbps
Transmission power: 23dBm; Conductive receiving sensitivity: -97dBm

Communication capability

V2X communication distance is more than 850m

GNSS

Supports GPS/GLONASS/BeiDou/Galileo/QZSS, L1+L5, data update rate 10Hz

Information safety

Built in special security chip, supporting the security national standard protocol,
with a signature verification capability of 2000+per second

Connectors

Electrical interface：One channel RJ45 network communication interface (100M/1000Mbps) compatible with POE power supply, built-in 2-way TTL level serial interface, 1-way USB interface;
Antenna interface: 2 * V2X antenna, 1 * combination antenna (integrated 5G * 4, L1+L5 dual band GNSS * 1, WiFi * 2)
